High Shear Mixing Granulator

High shear mixing granulator is used in pharmaceutical solid dosage area for mixing and granulation application.

Description

Introduction

High shear mixing granulator is used in pharmaceutical solid dosage area for mixing and granulation application. It’s the major processing equipment in solid dosage production line.
The equipment is PLC automation controlled and well satisfies the current GMP and Pharmacy Code regulation.

Working Principle

Since the material through a vacuum (such as the choice of the feeding mode), or other ways to feed into the bin, in the impeller under the action of mechanical force flow, forming trajectory, are mixed evenly in a silo, injecting adhesive, pelletizing knife open; material formed by adhesive bonding bridge formation in Masterbatch, mechanical energy conversion function, gradually grew up to meet the requirements of the wet particle.

Technical Data

Model	PT-GHL-10	PT-GHL-25	PT-GHL-50	PT-GHL-100	PT-GHL-150	PT-GHL-200	PT-GHL-300
Container volume	10L	25L	50L	100L	150L	200L	300L
Working volume	4-8L	10-20L	20-40L	40-80L	60-120L	80-160L	100-240L
Mixing speed	10-600rpm	5-420rpm	5-355rpm	5-287rpm	5-240rpm	5-223rpm	5-200rpm
Wet mill power	--	0.75Kw	0.75Kw	0.75Kw	1.5Kw	3Kw	3Kw
Compressed air consumption	0.03m3/min	0.05m3/min	0.05m3/min	0.1m3/min	0.1m3/min	0.2m3/min	0.2m3/min

Model	PT-GHL-400	PT-GHL-500	PT-GHL-600	PT-GHL-800	PT-GHL-1000	PT-GHL-1200
Container volume	400L	500L	600L	800L	1000L	1200L
Working volume	160-320L	200-400L	240-480L	320-640L	400-800L	480-960L
Mixing speed	5-185rpm	3-172rpm	3-162rpm	3-148rpm	3-140rpm	3-133rpm
Wet mill power	3Kw	4Kw	4Kw	4Kw	5.5Kw	5.5Kw
Compressed air consumption	0.2m3/min	0.3m3/min	0.3m3/min	0.3m3/min	0.3m3/min	0.3m3/min
